| # of tape cartridge slots |
8 |
 |
| # of tape drives |
1 |
|
| # of mail slots |
1 |
|
| Tape drives supported |
LTO6, LTO5 |
|
| Minimum Capacity |
LTO6: 20TB
LTO5: 12TB |
|
| Maximum Capacity |
LTO6: 50TB
LTO5: 24TB |
|
| Minimum data transfer rate |
LTO6: 576GB/hr
LTO5: 504GB/hr |
|
| Maximum data transfer rate |
LTO6: 1.4TB/hr
LTO5: 1TB/hr |
|
| Interfaces |
6GB SAS, 8Gb FC |
|
| Connectors |
Mini-SAS |
|
| Form Factor |
1u |
|
| Dimensions (inches) |
1.73"(h) x 18.98"(w) x 31.85"(d) |
|
| Dimensions (mm) |
43.94mm x 482.1mm x 808.9mm |
|
| Weight |
25.4 lbs. / 11.52kg |
|
| Power Requirements |
110 watts (max) |
|
| Input Requirements |
100 to 240 VAC, 50 to 60 Hz |
|
| Humidity (non-condensing; operating) |
10% to 80% |
|
| Temperature range (operating) |
10° to 35° C (50° to 95° F) |
|
| Reliability |
2,000,000 MCBF (robotic load/unload cycles) |
|
| Standard Warranty |
NEO S-Series libraries include one-year OverlandCare Bronze Support Coverage, which includes 5x9 telephone support and advanced parts replacement. |
