500GB, 1TB, 2TB or 3TB of hard disk or
128GB or 256GB of solid-state disk on one media |
| Read/Write Compatibility |
Forward/backward compatibility to all RDX drives and systems |
| Transfer Rate Average sustained |
USB3.0 -- Up to 260 MB/s, SATA -- Up to 45 MB/s |
| Average access time |
<15 ms |
| Interface |
SATA 1.0 or USB3.0 SuperSpeed |
| Interface Connector |
SATA: SATA, USB3.0: Type-B |
| Interface Operation Mode |
SATA: Removable Disk, USB3.0: Removable Disk & Fixed Disk |
| Mounting & Operation Orientation |
Horizontal or Vertical |
| Supported File Systems |
NTFS, FAT32, exFAT, ex2, ex3, ex4 and Mac OS Extended (HFS Plus) |
| Supported Operating Systems |
Windows XP, Windows Vista SP1, Windows 7, Windows 8, Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Small Business Server 2008, Small Buziness Server 2011, CentOS Linux, Fedora Core 5, RHEL, SLES |
| Media load-/ unload |
5,000 insertion/ removal cycles |
| Drive load-/ unload |
10,000 insertion/ removal cycles |
| MTBF drive |
550,000 Hours |
| Vibration (Maximum) |
0.5G (operating), 1.0G (non-operating) |
| Media Drop Shock (non-operating) |
1m drop to tile over concrete floor |
| Unrecoverable Error Rate |
1 error in 10(14) bits read |
| Temperature (operating) |
+10°C to +40°C (+50°F to +104°F) |
| Temperature (non-operating) |
-40°C to +65°C (-40°F to +149°F) |
| Relative Humidity (operating) |
20% – 80% (non-condensing) |
| Relative Humidity (non-operating) |
8% – 90% (non-condensing) |
| Altitude (ft. maximum-operating) |
-15 m to 3,048 m (-50 ft to 10,000 ft) |
| Altitude (non-operating) |
-15 m to 10,660 m (-50 ft to 35,000 ft) |
| Voltage |
internal drives: +5 V (SATA), +5 V or +12 V (USB)
external drives: +12V (standard USB drive), +5V (USB+ drive) |
| Current at Read/Write (Typical/Peak) |
internal drives: +5V: 0.9 A / 1.6 A (SATA), +12V: 0.005 mA / 1.4 A (USB)
external drives: 0.5 A / 1 A (standard USB drive), 0.9 A / 1.6 A (USB+ drive) |
| Power Connector internal drives |
SATA: SATA Power, USB: 4-Pin Molex |
| Power Connector external drives |
Standard USB drive: Wall Adapter: +12 V (+/-10%) 1.0 A, 5.5 mm
USB+ drive: optional Wall Adapter: +5 V (+/-10%) 2.4 A to +12 V (+/-10%) 1.0 A, 5.5 mm
|
| Regulatory Agency Approvals |
UL 60950, CSA C22.2 No. 60950, IEC 60950/ EN60950 |
| EMC |
FCC 47CFR, part 15, class B, CISPR22, class B, EN55022, class B, EN61000-3-2, EN61000-3-3, CISPR24, EN55024, ICES-003, class B, VCCI, CE, C-Tick |
| Warranty |
3-year Advanced Replacement Service |
| Height |
23 mm (0.90 in) – Piece of media (HDD and SSD)
41 mm (1.63 in) – 3.5in. Internal Drive
41 mm (1.63 in) – 5.25in. Internal Drive
52 mm (2.04 in) – External Drive |
| Width |
87 mm (3.40 in) – Piece of media (HDD and SSD)
102 mm (4.00 in) – 3.5in. Internal Drive
146 mm (5.78 in) – 5.25in. Internal Drive
110 mm (4.32 in) – External Drive |
| Length |
119 mm (4.70 in) – Piece of media (HDD and SSD)
159 mm (6.28 in) – 3.5" Internal Drive (Including bezel)
170.72 mm (6.72 in) – 5.25" Internal Drive (Including bezel)
178 mm (7.00 in) – External Drive (Including bezel) |
| Weight |
165 g (0.364 lb) – 272 g (0.600 lb) (HDD dependent) – Piece of media (HDD and SSD)
408 g (0.90 lb) – 3.5in. Internal Drive
635 g (1.40 lb) – 5.25in. Internal Drive
615 g (1.35 lb) – External Drive |
